DBA52123.1

Řada 5000 – hladký povrch – pouze rotor

Diameter [mm]	320
Thickness [mm]	22
Disc Vent	Kangaroo Paw
Annulus [mm] (Maximum useable pad width)	62,5
Pitch Circle Diameter (P.C.D.)	170
Inside Diameter [mm]	188
Diameter & Number of Bolt Holes [mm]	9.05 (x12)
Air Gap [mm]	9
Offset [mm]	1,5
Flange Inside Diameter [mm]	152
Flange Thickness [mm]	7
Hole Type	Round Hole
Stage	Stage 5
Tech Bulletins	Bedding in Brakes
Tech Bulletins	How to clean a Disc Rotor before fitting
Tech Bulletins	Motorsport - Important Info
Replacement Nuts	Not Included
