| Diameter [mm] | 234 |
| Disc Vent | Solid |
| Number of Holes | 4 |
| Minimum Thickness [mm] | 8,4 |
| Thickness [mm] | 10 |
| Height [mm] | 37.5 |
| Hole diameter[mm] | 62,5 |
| Tech Bulletins | Bedding in Brakes |
| Tech Bulletins | How to clean a Disc Rotor before fitting |
| Tech Bulletins | Motorsport - Important Info |
| Compatibility | |||||
|---|---|---|---|---|---|
| HYUNDAI | i-10 | 1.0 (2011-2014) | 2011-2014 | Rear | Disc Diameter [mm]: 234 |
| HYUNDAI | i-10 | 1.1 (2008-2014) | 2008-2014 | Rear | Disc Diameter [mm]: 234 |
| HYUNDAI | i-10 | 1.1 TD (2008-2014) | 2008-2014 | Rear | Disc Diameter [mm]: 234 |
| HYUNDAI | i-10 | 1.2 (2008-2014) | 2008-2014 | Rear | Disc Diameter [mm]: 234 |
| KIA | Picanto | 1.0 (2004-2011) | 2004-2011 | Rear | Disc Diameter [mm]: 234 |
| KIA | Picanto | 1.0 (2011-2017) | 2011-2017 | Rear | Disc Diameter [mm]: 234 |
| KIA | Picanto | 1.0 66BHP (2017-) | 2017- | Rear | Disc Diameter [mm]: 234 |
| KIA | Picanto | 1.0 Turbo 99BHP (2017-) | 2017- | Rear | Disc Diameter [mm]: 234 |
| KIA | Picanto | 1.1 (2004-2011) | 2004-2011 | Rear | Disc Diameter [mm]: 234 |
| KIA | Picanto | 1.1 TD (2004-2011) | 2004-2011 | Rear | Disc Diameter [mm]: 234 |
| KIA | Picanto | 1.25 (2011-2017) | 2011-2017 | Rear | Disc Diameter [mm]: 234 |
| KIA | Picanto | 1.25 83BHP (2017-) | 2017- | Rear | Disc Diameter [mm]: 234 |
