| Disc Vent | Solid |
| Diameter [mm] | 281 |
| Height [mm] | 55 |
| Thickness [mm] | 12 |
| Minimum Thickness [mm] | 10.5 |
| Inner Diameter [mm] | 62 |
| Number of Holes | 5 |
| Weight | 5.18 |
| Tech Bulletins | Bedding in Brakes |
| Tech Bulletins | How to clean a Disc Rotor before fitting |
| Tech Bulletins | Motorsport - Important Info |
| Axle | Rear |
| ECE R90 number | E11 90R-02C01704/72742 |
| Compatibility | |||||||
|---|---|---|---|---|---|---|---|
| TOYOTA | Rav 4 | 2.0 (2006-2013) | 2006-2013 | Brake Caliper: Akebono | Rear | Brake Pads: DB1832 | Disc Diameter [mm]: 281 |
| TOYOTA | Rav 4 | 2.0 (2013-2018) | 2013-2018 | Brake Caliper: Akebono | Rear | Brake Pads: DB1832 | Disc Diameter [mm]: 281 |
| TOYOTA | Rav 4 | 2.0 TD (2013-2018) | 2013-2018 | Brake Caliper: Akebono | Rear | Brake Pads: DB1832 | Disc Diameter [mm]: 281 |
| TOYOTA | Rav 4 | 2.2 TD (2006-2013) | 2006-2013 | Brake Caliper: Akebono | Rear | Brake Pads: DB1832 | Disc Diameter [mm]: 281 |
| TOYOTA | Rav 4 | 2.2 TD (2013-2018) | 2013-2018 | Brake Caliper: Akebono | Rear | Brake Pads: DB1832 | Disc Diameter [mm]: 281 |
| TOYOTA | Rav 4 | 2.5 Hybrid (2016-2018) | 2016-2018 | Brake Caliper: Akebono | Rear | Brake Pads: DB1832 | Disc Diameter [mm]: 281 |
