| Diameter [mm] | 316 |
| Disc Vent | Kangaroo Paw |
| Number of Holes | 10 |
| Inner Diameter [mm] | 58 |
| Minimum Thickness [mm] | 28 |
| Thickness [mm] | 30 |
| Height [mm] | 56.7 |
| Pitch Circle [mm] | 100 & 114.3 |
| Tech Bulletins | Bedding in Brakes |
| Tech Bulletins | How to clean a Disc Rotor before fitting |
| Tech Bulletins | Motorsport - Important Info |
| Compatibility | ||||||
|---|---|---|---|---|---|---|
| SUBARU | Forester | 2.0 150BHP (2013-2018) | 2013-2018 | Front | Brake Pads: DB1722 | Disc Diameter [mm]: 316 |
| SUBARU | Forester | 2.0 TD 147BHP (2013-2018) | 2013-2018 | Front | Brake Pads: DB1722 | Disc Diameter [mm]: 316 |
| SUBARU | Forester | 2.0 Turbo 240BHP (2014-2019) | 2014-2019 | Front | Brake Pads: DB1722 | Disc Diameter [mm]: 316 |
| SUBARU | Legacy | 2.5 Turbo 265BHP (2009-2014) | 2009-2014 | Front | Brake Pads: DB1722 | Disc Diameter [mm]: 316 |
| SUBARU | Legacy | 3.0 245BHP (2003-2010) | 2003-2010 | Front | Brake Pads: DB1722 | Disc Diameter [mm]: 316 |
| SUBARU | Levorg VM | 1.6 Turbo 170BHP (2015-2021) | 2015-2021 | Front | Brake Pads: DB1722 | Disc Diameter [mm]: 316 |
| SUBARU | Outback | 2.0 TD 150BHP (2015-) | 2015- | Front | Brake Pads: DB1722 | Disc Diameter [mm]: 316 |
| SUBARU | Outback | 2.5 175BHP (2015-) | 2015- | Front | Brake Pads: DB1722 | Disc Diameter [mm]: 316 |
| SUBARU | Outback | 3.6 260BHP (2009-2014) | 2009-2014 | Front | Brake Pads: DB1722 | Disc Diameter [mm]: 316 |
| SUBARU | Tribeca | 3.0 (2005-2008) | 2005-2008 | Front | Brake Pads: DB1722 | Disc Diameter [mm]: 316 |
| SUBARU | Tribeca | 3.6 (2007-2014) | 2007-2014 | Front | Brake Pads: DB1722 | Disc Diameter [mm]: 316 |
